The inch gauges for U.S.A and Canada markets conform to ANSI specifications with anvil thread #4-48 UNF and clamping stem dia. 3/8inch.
The metric gauges for markets like India, Europe, South America, Japan etc. conform to IS, ISO & DIN JIS specifications with anvil thread M2.5 and clamping stem dia. 8mm.
| Technical Data Sheet | ||||
|---|---|---|---|---|
| Bezel dia | Type | Reading | Range | Graduation |
| 56mm | J01 | 0.01mm | 10.0mm | 0-50-0 |
| 56mm | J02 | 0.01mm | 10.0mm | 0-100 |
| 56mm | J03 | 0.01mm | 5.0mm | 0-50-0 |
| 56mm | J04 | 0.01mm | 5.0mm | 0-100 |
| 56mm | J05 | 0.1mm | 10.0mm | 0-10 |
| 56mm | J06 | 0.1mm | 25.0mm | 0-10 |
| 56mm | J08A | 0.01mm | 25.0mm | 0-100 |
| 56mm | JZ | 0.01mm | 0.8mm | 40-0-40 |
| 56mm | JO9A | 0.002mm | 2.0mm | 0-10-0 |
| 56mm | J10A | 0.002mm | 2.0mm | 0-20 |
| 56mm | J11A | 0.002mm | 5.0mm | 0-10-0 |
| 56mm | J12A | 0.002mm | 5.0mm | 0-20 |
| 56mm | J13 | 0.002mm | 12.0mm | 0-10-0 |
| 56mm | J14 | 0.002mm | 12.0mm | 0-20 |
| 56mm | J17A | 0.001mm | 1.0mm | 0-100-0 |
| 56mm | J50A | 0.001inch | 1.0inch | 0-100 |
| 56mm | J51 | 0.001inch | 0.5inch | 0-50-0 |
| 56mm | J52 | 0.001inch | 0.5inch | 0-100 |
| 56mm | J53 | 0.0005inch | 0.5inch | 0-25-0 |
| 56mm | J54 | 0.0005inch | 0.5inch | 0-50 |
| 56mm | J61A | 0.0001inch | 0.20inch | 0-50-0 |
| 56mm | J62A | 0.0001inch | 0.20inch | 0-100 |
| 56mm | J63 | 0.0001inch | 0.50inch | 0-50-0 |
| 56mm | J64 | 0.0001inch | 0.50inch | 0-100 |
| 56mm | JY | 0.001inch | 0.08inch | 40-0-40 |
