• Fast, accurate measurement.
  • Resolution 0.001mm (0.00005”).
  • Tungsten carbide measuring faces on all 3-point heads from 12.5mm.
  • Blind bore measurement above 12.5mm (0.500”).
  • Extensions available for deep hole measurement.
  • Setting rings included with individual instruments and sets.
  • UKAS certificates supplied with all gauges.
  • Serial number on all gauges and measuring heads.
  • Heads with special anvils available to suit specific customer requirements.
    (e.g. Threads, grooves, 2-point, spherical, splines etc).
  • Bore gauges manufactured according to DIN 863, part 4.
  • Measuring range 6-100mm ( diameters above 100 on request ).
  • Excellent for vertical bore measurement.
  • Simple 2-button operation.
  • 3 preset memories.
  • RS-232 output.
  • Self-centering heads.
  • Constant measuring pressure.
